GPV-60-24E Constant Voltage LED Power Supply - 24 Volt - 2.5 Ampere - 60 Watt

Manufacturer:

This waterproof power supply is ideal for powering 24 volt LED lighting up to 2.5 ampere.

14,25 € incl. VAT, excl. shipping

Webwinkel Keurmerk

More info

Global Leader Power GPV-E series

The GPV-E series from Global Leader Power is similar to the popular GPV series, however, these power supplies only accept European mains voltages from 180 to 264 volts. This allows these power supplies to be a bit smaller and cheaper. Like the GPV series, these LED power supplies are waterproof (IP67), allowing you to use them for example outdoors. They are also suitable for installation on furniture made of materials with unknown flammability properties. In addition they meet all safety requirements and include short-circuit protection, among other things.

Data sheet

IP code IP67
Output voltage 24 volt
Output current 2.5 ampere
Power 60 watt
Line regulation ±1%
Load regulation ±2%
Tolerance ±3%
Ripple and noise 200 millivolt peak to peak
Input voltage 180 to 264 volt
Input frequency 47 to 63 hertz
Efficiency 86%
Leakage current 0.25 milliampere
Setup time 600 milliseconds
Rise time 25 milliseconds
Hold up time 20 milliseconds
Protection Over current, Over voltage, Short circuit
Working temperature -20 to 70 °C
Working humidity 20 to 90%
Storage temperature -40 to 80 °C
Storage humidity 10 to 95%
